Specification
|
|
|
Air Flow Capacity (CFM) |
Approx 3000
|
|
Pressure Drop (Inches W.C.) |
0.01 |
|
Housing Material Aluminum |
Aluminum / 316SS |
|
Weight (lbs) |
1.5 lb
|
|
Max Operating Temperature (F) |
160 |
|
Dimensions - Inches (L x W x H) |
18 x 0.75 x 0.75 |
|
 |
|
|
Electrical |
|
|
Voltage*; |
115 / 230 VAC |
|
Power Consumption |
60 Watts |
|
Current Draw (Amps) |
0.50 / 0.25 |
|
Frequency (Hz) |
50 or 60 |
|
Internal Fuse |
1 |
|
Field Electrical Connections** |
3 Prong Power Cord |
|
Approvals / Listings |
UL / cUL |
|
|
|
|
*AAS power supply is dual voltage rated by selector switch |
|
**A power cord is provided with each AAS power supply
that has a 3 prong connector. If 230VAC is required, the end
must be snipped off and hard wired to a junction box.
|
